Product Specifications
General & Temperature Control
- Temperature Range: 65 °C to 300 °C
- Temperature Stability: ±0.02 K
- Display Resolution: 0.01 K
- Controller: Pilot ONE with 5.7" touchscreen
- Safety Class: Class III / FL
- Protection Class: IP20
- Alarm Messages: Optical, acoustic, relay
- Dimensions (W × D × H): 240 × 427 × 393 mm
- Net Weight: 23 kg
Heating Capacity
- Heating Power: 2.7–3.0 kW (depending on voltage)
Circulation Pump
- Maximum Flow Rate: 45 L/min
- Maximum Pressure: 0.9 bar
- Pump Connection: M24×1.5 male thread
- Maximum Permissible Viscosity: 50 mm²/s
- Pump Speed: Adjustable
- Pump Characteristics: Pressure pump, variable speed
Connectivity & Interfaces
- External Sensor Connection: Pt100
- Digital Interfaces: 2× USB (Host & Device), Ethernet, RS232
Operating Conditions
- Permissible Ambient Temperature: 5 °C to 40 °C
- Minimum Filling Volume: 1.45 L
- Expansion Volume: 2 L
- Power Supply: 200–240 V, 1~/2~, 50/60 Hz
- Maximum Current Consumption: 15.5 A
- Fuse Protection: 16 A
Notable Features
- Adaptive Temperature Control: Self-optimizing for precise and reproducible results
- Pilot ONE Controller: Intuitive operation with a 5.7" touchscreen and multilingual menu navigation
- Efficient Operation: Hydraulically sealed system minimizes thermal fluid oxidation and vapor formation, extending fluid life and reducing maintenance
- Connectivity: Multiple interfaces for easy integration into laboratory networks and remote monitoring
- Compact Design: Small footprint saves valuable laboratory space without compromising performance
