Product Specifications
Technical Specifications:
- Speed Range: 10–2,000 rpm
- Maximum Torque: 200 Ncm
- Maximum Viscosity: 100,000 mPa·s
- Maximum Volume (H₂O): 50 liters
- Motor Type: EC motor
- Speed Control: Electronic, with ±1% accuracy
- Display: 2.4-inch monochrome digital display (Expert model) or 3.2-inch color display (Ultimate model)
- Interfaces: USB and RS232 (Ultimate model)
- Protection Class: IP54
- Dimensions (W × H × D): 86 × 350 × 247 mm
- Weight: 5.1 kg
- Power Input: 120 W
- Operating Temperature Range: 5°C to 40°C
- Shaft Diameter: 2.5–10.5 mm
- Continuous Operation: Yes
- Overheat Protection: Automatic cut-out with display
Key Features:
- High Torque Performance: Delivers up to 200 Ncm torque, suitable for high-viscosity applications.
- Wide Speed Range: Adjustable from 10 to 2,000 rpm for versatile stirring needs.
- User-Friendly Interface: Digital display for easy monitoring and control of stirring parameters.
- Safety Features: Start/stop touch function to prevent unintentional operation; automatic overheat protection.
- Quick-Action Chuck: Allows for easy and secure attachment of stirring tools without additional equipment.
- Data Connectivity: USB and RS232 interfaces enable integration with laboratory software and automation systems (Ultimate model).
- Quiet Operation: Advanced motor technology ensures minimal noise during operation.
Ideal Applications:
- Chemical synthesis and processing
- Pharmaceutical formulation
- Biotechnology and life sciences research
- Food and beverage quality control
- Cosmetic product development
