Product Specifications
Technical Specifications
- Pumping Speed (60 Hz): 222 L/min (7.8 CFM)
- Pumping Speed (50 Hz): 174 L/min (6.1 CFM)
- Ultimate Pressure: 8 mbar (6 Torr)
- Motor Power (50 Hz): 370 W
- Motor Power (60 Hz): 440 W
- Operating Speed (60 Hz): 1,450 RPM
- Operating Speed (50 Hz): 1,200 RPM
- Inlet/Outlet Connection: DN16 KF flange (standard); optional 10 mm hose barb
- Maximum Inlet Pressure: 1.0 atmosphere (0 psig)
- Maximum Outlet Pressure: 1.0 atmosphere (0 psig)
- Noise Level: 48 dB(A)
- Operating Temperature Range: +10°C to +40°C (50°F to 104°F)
- Cooling System: Air-cooled
- Weight: 32.8 kg (72.3 lbs)
- Dimensions (W × D × H): 570 × 270 × 310 mm (22.4 × 10.6 × 12.2 in)
- Power Supply: 230 VAC, 50/60 Hz, single-phase
- Motor Thermal Protection: Automatic thermal protection
- Certifications: CE, RoHS compliant
Key Features
- Oil-Free Operation: Ensures a clean vacuum environment, eliminating the risk of oil contamination.
- Chemical-Resistant Design: Components are designed to handle a variety of laboratory gases and vapors.
- Quiet and Low Vibration: Operating at 48 dB(A), suitable for noise-sensitive environments.
- User-Friendly Maintenance: Diaphragm replacement recommended every 10,000 operating hours.
- Versatile Applications: Ideal for vacuum filtration, drying, distillation, and general laboratory vacuum applications.
Ideal Applications
- Vacuum Filtration
- Vacuum Drying
- Vacuum DistillationCole-Parmer
- General Laboratory Vacuum Applications
